This board is installed the FZYNQ-FPGA which integrated DualCore ARM Cortex-A9 possessor and programmable logic.
 ・the parts usable in vacuum condition.
 ・ DDR3 memory 1GB, GigabitETHER, SD card,
   USB2.0、USB3.0、SpW ports and extension connectors.

CPU-

  • Product Image
  • Specification
  • Documents
  • Block Diagram
  • SOC(MPU/FPGA) ZYNQ(XC7Z045-1FFG900)
    Memory 1GB DDR3-1066 4Gbit(16bit)×2
    256MB DDR2-666 2Gbit(16bit)×1
    32MB 256Mbit S25FL256SAGMFI00 ×1
    Extension Connector PCIe  4 Lane connector on board
    LVDS IO Total Ch 48ch
    LVCMOS33 Total CH 100ch
    Operating Condition usable in vacuum condition.
    Inter Face SpaceWire  ×3 ports
    GigaBit Ether ×1 port
    USB2.0 HOST  × 1 port
    USB3.0 HOST  × 2 portト
    Serial Console
    Power 12V±10%
    Operating Temp. 0℃~50℃
    Board Size 200×150 ㎜ (Excluding protrusions)
  • Brochure ZDAQ_SoC_SP28E2101.pdf
