Wallaby-721021

Wallaby-721021
Embedded RZ/A1L Board (Reduced SBEV-RZ/A1L Peripheral function board)

This board is reduced peripheral function board from SBEV-RZ/A1L board and it can embedded to the system.
This board CPU is 208 pin package RZ-A1L (Renesas electronics)

CPURZ/A1L(ARM Cortex9/400MHz)

  • Product Image
  • Specification
  • Documents
  • Information
  • Blick Diagram
  • RZ/A1L ARM Cortex A9 400MHz
    L2 Cash : 128KB 133MHz
    Memory SRAM : CPU build in SRAM 3MB
    DRAM : 64MB
    Boot ROM 2MB (Serial Flash ROM)
    I/O 100BASE Ether : RJ-45
    USB-HOST : Type-A
    USB-Device : mini-B
    SD Card : Micro SD Card
    RS232 serial: D-sub9
    拡張IO : 40 pin header (2.54 pitch)
    Real Time Clock back up time : about 2 weeks
    Operating temp. -10℃ ~ 60℃
    Power Consumption 5V/0.5A
    Power input : AC adapter or USB power
    Size 88(W)×141(D) mm
  • Brochure Wallaby-721021-SP23E7008.pdf
  •  Support OS


    Linux     (Paid support by Shimafuji)
    uC3/Standard (e・forcve Free evaluation version)
       Renesas RZ/A Series for IAR μC3+μNet3/Standard download (evaluation version)
       Renesas RZ/A Series for DS-5 μC3+μNet3/Standarddownload (evaluation version)
      Supported development environment:EWARM、DS-5
      Supported TAG-ICE:Partner-Jet2、I-Jet etc.
